| उत्पत्ति के प्लेस: | यूएसए |
| ब्रांड नाम: | Allen Bradley |
| प्रमाणन: | CO.CQ |
| मॉडल संख्या: | 1770-सी.डी |
|
Product Description |
|
|
The 1770-CD is a twinaxial shielded communication cable manufactured by Allen‑Bradley for use in “Data Highway” style networks (for instance the DH / DH+ networks) within industrial automation systems.It is sold in lengths (e.g., one source lists a 100 ft / 30 m length) and “cut-to-length” pricing.It pairs two conductors (20 AWG) in a twinaxial configuration, with dual shielding (foil + braided) and a drain/ground wire. |
|
| More Technical Data | |
| Conductor | 20 AWG (stranded, 7 × 28 tinned copper) |
| Insulation | Polyethylene (PE) for the conductor pair; colour-coded Clear & Blue. |
| Temperature rating | Operating range –40 °C to +80 °C; UL temperature rating 80 °C. |
| Max recommended pulling tension | ~48 lbs (≈ 22 kg) for one variant. |
| Frequently Asked Questions | |
|
Q1: What is the difference between 1770-CD and Belden 9463? For example, the Allen-Bradley installation manual says: “Use Twinaxial Cable (cat. no. 1770-CD, Belden 9463 or equivalent)…” So 1770-CD is essentially the same cable specification as Belden 9463 (or at least designed to meet that spec). Q2: Is this cable still in production / available? modern equivalent cable that meets the same spec (20 AWG twinax, foil+braid shield, characteristic impedance ~78 Ω etc). Q3: Can I use this cable for any data network (e.g., Ethernet)? Ethernet twisted-pair or 50/75 Ω for coax) and the network protocol (DH / DH+) is specific. Use only in the context of the supported network. For other uses you’d want to match impedance, shielding, and signalling requirements. Q4: What is the maximum trunkline length I can use with this cable? ft (≈ 3,050 m) in length under ideal conditions. However actual maximum may depend on bus loading, number of nodes, dropline lengths, noise environment. |
|
